Description:
This is a single-chip controller/driver for 262K-color, graphic type TFT-LCD. It consists of 396 source line and 162 gate line driving circuits. This chip is capable of connecting directly to an external microprocessor, and accepts Serial Peripheral Interface (SPI), 8-bit/9-bit/16-bit/18-bit parallel interface.
Display data can be stored in the on-chip display data RAM of 132 x 162 x 18 bits.
Features:
Display Colors (Color Mode):
Full Color: 262K, RGB=(666) Max., Idle Mode OFF
Color Reduce: 8-color, RGB=(111), Idle Mode ON
LCD Driver Output Circuits:
Source Outputs: 132 RGB Channels
Gate Outputs: 162 Channels
Common Electrode Output
Support Both Normal-black & Normal-white LC
Software Programmable Color Depth Mode
Partial Window Moving & Data Scrolling
Built-in Circuits:
DC/DC Converter
Adjustable VCOM Generation
Non-volatile (NV) Memory to Store Initial Register Setting
Oscillator for Display Clock Generation
Factory default value (module ID, module version, etc) are stored in NV memory.
Timing Controller
Parameters:
Resolution: 128x160
Driver: ST7735
Power Supply: 5V
Interface: I2C
Application: Arduino
Instruction and Document Download Link: https://drive.google.com/drive/folders/1TnI11iVNIAmHYrTuW_EMTs_RG-VNEeyI
Packing List:
1 * 1.8inch I2C Graphic Color Screen TFT LCD Display Module
