micro: Maqueen Lite-micro:bit Educational Programming Robot Platform

INTRODUCTION

I am Maqueen

Hello, my name is Maqueen, is a graphical programming robot for STEM education, which inherits playability and simple operation of micro:bit. The Mini-body, interesting features and plug-and-play allow children to quickly learn graphic programming in entertaining, nurturing children's interest in science and logical thinking.

Suggest Age: 8 +

Maqueen is accessible to Mind+ Programming platform now. Mind+ is a Scratch3.0-based graphical programming platform from DFRobot, supporting python, Arduino and other programming platforms. At present, Mind+ has been applied to all kinds of sensors, modules and related educational products.micro: Maqueen (with micro:bit), micro: Maqueen

micro: Maqueen micro:bit Educational Programming Robot Platform micro: Maqueen micro:bit Educational Programming Robot Platform micro:bit - an Educational & Creative Tool for Kids, micro:bit micro: Maqueen micro:bit Educational Programming Robot Platform micro: Maqueen micro:bit Educational Programming Robot Platform micro: Maqueen micro:bit Educational Programming Robot Platform mindplus, mind +, mind+ micro: Maqueen micro:bit Educational Programming Robot Platform
micro: Maqueen micro:bit Educational Programming Robot Platform

Crazy Maqueen Tutorial micro: Maqueen micro:bit Educational Programming Robot Platform micro: Maqueen micro:bit Educational Programming Robot Platform


FEATURES
Support for Makecode, will support Scratch and python later.
Small size, flexible movement.
All-metal miniature gear motor, good quality, strong driving force.
Line patrol, ambient light, LED lights, ultrasonic interface, buzzer, I2C interface, mechanical expansion screw hole, etc. ... full-featured, highly expandable.
Exclusive customized POM bearing wheel, flexible and reliable, strong obstacle crossing ability.
Easy to install, easy to use.
SPECIFICATION
Supply Voltage: 3.5V~5V DC ( Three AAA batteries or 3.6V~3.7V lithium battery )
Infrared Grayscale Sensor(High-low level) x 2
Buzzer x 1
Infrared Receiver (NEC decoder) x 1
LED Lights (High-low level control) x 2
RGB Ambient Light (16 million colors) x 4
SR04, SR04P Ultrasonic Interface(5V) x 1
I2C Interface (3.3V) x 1
Gravity Extension Interfaces (P1, P2) x 2
N20 All-metal Gear Motor x 2
Motor Reduction Ratio: 1:150
Maximum Rotate Speed: 133 rpm
Motor Drive Mode: PWM motor drive
Bracket and Protective Cover Extension M3 Screw Hole x 6
Programming Method: Makecode graphical programming, Mind+ graphical programming (based on Scratch 3.0)
Dimension: 81mm x 85 mm x 44mm/3.19 x 3.35 x 1.73in
Weight: 75.55g
